Explosion-proof conductive slip ring is a kind of slip ring with high safety and reliability, suitable working in explosive environment, such as oil platform, explosive material packaging equipment, agricultural products processing equipment, coal mine, spraying and other dangerous places. It can meet both explosive gas environment and explosive dust environment and the protection grade is IP65 IP66 or IP68.
ECN-EX-04P | Specification |
Current | 4*100 A |
Voltage | 660VAC |
Dielectric strength | ≥2500VAC@50Hz |
Isolation resistance | ≥500MΩ@100VDC |
Resistance fluctuation | 10mΩ |
Operating speed | 0~50rpm |
Contact material | Copper graphite |
Anti-explosion grade | Exd II BT4 Gb IP65 |
Protection grade | IP65 |
Outline drawing
