Combine switch signal and profibus,profinet,RS and so on.As well as power current.The transmition of sensitive signal via slip ring is the key point for this slip ring design. In order to avoid external interference of the slip ring and prevent the internal interference of slip ring.Gold contact provides high reliability performance in design.
Feature
Special wiring design
Gold to gold contact material
Customized specification
Flexible installation
| Model | ID (mm) | OD (mm) | CKT No. | Current/Signal | Voltage | Working speed | Spec |
|---|---|---|---|---|---|---|---|
| ECN000-08P1-24S | 0 | 56 | 32 | 8*5 A, 10*sensor signal,14*servo motor encoding signal | 380VAC/VDC | 0~500rpm |  |
| ECN000-29P-21S | 0 | 86 | 50 | 4*10A,25*2A,13*signal,8*servo motor | 0~380VAC/VDC | 0-100 rpm | |
| ECN000-33P-42S | 0 | 86 | 75 | 8*10A,25*2A,26*signal,16*servo motor | 0~380VAC/VDC | 0-100 rpm |  |
| ECN000-12P2-18S | 0 | 99 | 30 | 12*10A; 18*signal | 380VAC | 0~300rpm | |
| ECN030-28P2-83S | 30 | 99 | 111 | 28*10A , 11*signal,1*PE, 6 group servo motor encoder signal | 0-380VAC/VDC | 0-20 rpm | |
| ECN038-06P2-10S | 38 | 99 | 16 | 6*10A; 10*2A(servo motor signal) | 0-380VAC/VDC | 0~300rpm | |
| ECN080-20P-44S-02EG | 80 | 160 | 66 | 2*64A,10*10A,8*4A,16*switch signal,4*Can,2*Servo motor,2*1000M Ethernet | 0~380VAC/24VDC | 0-100 rpm | |
