Electric slip ring and pneumatic or hydraulic rotary unions combined slip ring is designed for some special applications that require both electric ring and pnuematic or hydraulic rotary unions. CENO takes its own technical advantages to developed this kind of slip ring, which is more convenient for users in installation and operation.This kind of slip-ring can be integrated with current and signal of different specifications according to specific requirements, and pnuematic or hydraulic rotary union can be selected for different types base on different applications requirement. This kind of slip ring is currently used around the world to ensure reliable transmission of signal and power, well performance process.
Characteristics
Different sealing forms can be selected according to different applications.
Stable performance and long lifespan;
The slip ring part can integrate current and various signals.
The number of electric circuits can reach hundreds, and the gas and liquid channels can reach 16 channels.
The external dimension and installation method can be customized
Application
Automation equipment
Chemical pharmacy
Machinery manufacturing
Food processing
Iron and steel metallurgy
Plastic fiber manufacturing
| Model | ID (mm) | OD (mm) | CKT No. | Current/Signal Voltage | Air/water channel | Pressure | Working speed rpm | Spec |
|---|---|---|---|---|---|---|---|---|
| QCN01M6-02P1 | 0 | 50 | 3 | 2 * Electrical Signal / 24VAC/VDC | 1 *gas | -100KPa ~ 0.6MPa | 0~60 |  |
| QCN0102-06S | 0 | 86 | 3 | 2 * Signal / 24VAC/VDC | 1 *gas | ≤1.0MPa | 0~250 | |
| QCN0101-02P1-IP65 | 0 | 55 | 3 | 2 * Electric Power /24VAC/VDC | 1*air | -100KPa~1.2MPa | 0~200 | |
| QCN0102-02P1-01EM | 0 | 99 | 4 | 3 * Electric & Ethernet Signal | 1*air | ≤8 Bar | 0~250 | |
| QCN0102-03P | 0 | 100 | 4 | 3 * Electric Power /380VAC/VDC | 1*water (G1/4") | ≤4MPa | 0-100 |  |
| QCN01M6-02P-02S | 0 | 55 | 5 | 4 * Electric & Signal /12VAC/VDC | 1*air | -100KPa~1MPa | 0-300 |  |
| QCN0103-03P3-01EM | 0 | 99 | 5 | 5 * power & Ethernet / 400 VAC / VDC | 1 *gas | ≤6 Bar | 0~250 | |
| QCN0101-04P2-01EM-A | 0 | 86 | 6 | 5 * power & Ethernet / 220 VAC / VDC | 1*air | -100KPa~1.0MPa | 0~50 | |
| QCN0101-03P2-02P1-01EG | 0 | 86 | 6 | 5 *power & Ethernet /380VAC | 1*air | 1.0MPa | 0~50 |  |
| QCN01M6-06P1 | 0 | 55 | 7 | 6 * Electric power / 24VAC / VDC | 1 * Air | -100KPa ~ 1MPa | 0~250 |  |
| QCN0102-05P-01EM | 0 | 65 | 7 | 6 * Electric power & Ethernet /24VAC/VDC | 1 *gas | 10Bar | 0~100 |  |
| QCN0101-25-05P3-01EM | 25.4 | 86 | 7 | 6 * Electric power & Ethernet / 400 VAC/VDC | 1*air | 7 Bar | 0~30 | |
| QCN0102-03P1-05S | 0 | 86 | 9 | 8 * Electric power & signal / 380VAC | 1*gas | ≤1.0MPa | 0-300 |  |
| QCN0103-08P2 | 0 | 99 | 9 | 8 * Electric power / 24VAC/VDC | 1*gas | ≤ 10 Bar | 0~250 | |
| QCN0103-06P-03EM-1 | 0 | 86 | 10 | 9 * Power & profinet / 400 VAC/VDC | 1 *air | ≤ 8 Bar | 0~50 | |
QCN0103-06P-03EM-2 | 0 | 86 | 10 | 9 * Power & profinet / 400 VAC/VD | 1 *air | ≤ 8 Bar | 0~50 | |
| QCN0103-10P2 | 0 | 99 | 11 | 10 * Electric power | 1* gas | ≤ 10 Bar | 0~250 | |
| QCN0101-11S | 0 | 55 | 11 | 11 * Signal / 12VDC | 1 *air | ≤ 8Bar | 0-300 | |
| QCN0103-04P1-05PE-02EG | 0 | 99 | 11 | 11 * Electric power & Signal / 380VAC/24VDC | 1*air | 1 MPa | 0~250 |  |
| QCN01M5-04P1-08S | 0 | 50 | 13 | 13 * Electric& Encoder Signal | 1*air | -100KPa ~ +1.0MPa | 0~250 | |
| QCN0103-10P-04EG | 25.4 | 99 | 14 | 14 * Electric power / 380VAC/VDC | 1*gas(G3/8") | - 100Kpa~1Mpa | 0-300 | |
| QCN0103-04P2-12P1 | 0 | 86 | 17 | 16 * Electric power / 220VAC/VDC | 1*gas (G 3/8") | 1.0MPa | 0~60 | |
| QCN0101-25P | 0 | 56 | 25 | 25 * Electric Signal & Encoder / 24VAC/VDC | 1 *gas | 1.0MPa | 0-50 | |
| QCN0101-12P-14S-01UA-01EM | 0 | 99 | 28 | 28 * Electric & USB & Ethernet / 440VAC/VDC | 1*air | <1.0MPa | 0~250 | |
| QCN0101-30S | 0 | 86 | 30 | 30 * Signal / 24VAC/VDC | 1*air | -100Kpa~+1.0MPa | 0~250 | |
| QCN0104-36P | 0 | 119 | 36 | 36 * Electric Power | 1*air | 10 Bar | 0~250 | |
| QCN0102-08P2-14P1-26S-01EG | 0 | 86 | 49 | 49 * Electrical * Signal * Ethernet / 380 VAC/VDC | 1*air | 0.4~0.7MPa | 0~10 |  |
| QCN0104-50S | 0 | 99 | 51 | 50 * Signal / 220 VAC/VDC | 1*air | 1.0 MPa | 0~100 | |
| QCN0201-06P1 | 0 | 86 | 8 | 6 * Electric Signal | 2*air | 0.6 Mpa | 0~3 | |
| QCN0201-08P1 | 0 | 56 | 10 | 8 * Electric Signal | 2*air | 1.00KPa ~ 0.6 MPa | 0~30 | |
| QCN0201-06P3-04P1-01EG | 0 | 86 | 13 | 11 * Electric & Ethernet / 480VAC/VDC | 2*air | ≤ 8 Bar | 0~50 |  |
| QCN0201-24P-18S-03EG | 0 | 61 | 45 | 23*10A; 1*PE; 21*Ethernet / 220 VAC/VDC | 2*air | -100KPa ~ +0.8MPa | 0~300 | |
| QCN0201-48S | 0 | 90 | 50 | 48 * Signals / 24VDC | 2*Gas | 6Bar | 0-80 |  |
| QCN0201-60-02P-IP65 | 60 | 155 | 6 | 4 * Electric Power | 2 * water | 1.0MPa | 0~50 | |
| QCN0201-85-08P-04S-02EG | 0 | 160 | 16 | 14 * Electric Signal & Ethernet / 380VAC/VDC | 2*air | 0.5 MPa | 0~150 | |
| QCN0202-36S | 0 | 75 | 38 | 36 * Signals / 24VDC | 2*air | -100KPa~ 0.5MPa | 0-60 |  |
| QCN0202-04P2-04S-01EM | 0 | 95 | 11 | 9 * Electric Power & Ethernet / 140VAC/VDC | 1*air, 1*water | 8 Bar (aire & water) | 0-70 | |
| QCN0202-10P1-05S | 0 | 100 | 17 | 15 * Electric Signal / 24VAC/VDC | 2*Gas G1/4″ | ≤ 6Bar | 0-30 | |
| QCN0203-04P2-04S-02EG | 0 | 86 | 10 | 8 * Electric & Ethernet /220VAC/VDC | 2*air | 0.9MPa | 0~100 | |
| QCN0203-EX-12P1-16S-01EG | 0 | 99 | 31 | 29 * Electric Signal Ethernet / 220VAC/VDC | 1* Nitrogen, 1* air | 1.0MPa | 0~30 | |
| QCN0203-03P3-47S | 0 | 105 | 52 | 50 * Electric / Ethernet / HDMI / 220VAC/VDC | 2*water(G3/8") | ≤1.0MPa | 0-100 | |
| QCN0203-04P2-25S-01EG | 0 | 130 | 32 | 30 * Electric Signal Ethernet / 24VAC/VDC | 2*air | ≤ 6.5Bar | 0~10 | |
| QCN0203-07P1 | 0 | 200 | 9 | 7 * Electric Signal | 2 * gas (2*in, 1*out) | ≤ 8 Bar | 0~10 | |
| QCN0204-16P1-16S | 0 | 110 | 22 | 20 * Electric Signal / 220VAC/VDC | 2*gas | 1.0MPa | 0~50 | |
| QCN0204-10P2-08S | 0 | 120 | 14 | 12 * Electric & Signal | 2*gas (G 3/8") | 1.0MPa | 0-50 | |
| QCN0208-72P | 0 | 116 | 74 | 72 * Electric / Signals / 380VAC/VDC | 1*gas 1*vac | ≤ 8 bar | 0~100 | |
| QCN0301-06P2-21S-03EG | 0 | 95 | 25 | 18*Power/Signal, 4*Encoder/Ethernet / 24 VAC/VDC | 3*gas | 1.0MPa | 0-50 | |
| QCN0301-08P-04S-02EG | 0 | 100 | 17 | 14 * Electric / Ethernet /380VAC/VDC | 3*air | 5MPa | 0~150 | |
| QCN0301-04P-20S-02EG-12U2 | 0 | 120 | 41 | 38 * Electric / USB / Ethernt / 220VAC/VDC | 3*Gas, G1/8″ | ≤ 1.0MPa | 0-5 | |
| QCN0302-06P-01EM | 0 | 91 | 10 | 7 *Electric / Ethernet /240 VAC/VDC | 3*Gas ,G1/4” | 10 Bar | 0 ~ 50 | |
| QCN0302-18P2-16S-01EM | 0 | 125 | 25 | 22 * Electric / Signal / Ethernet | 3*Air | ＜0.8MPa | 0-250 | |
| QCN0304-18P2-16S-01EM | 0 | 125 | 25 | 22 * Electric / Signal / Ethernet / 380VAC/VDC | 3*gas | -95KPa~0.8MPa | 0-250 |  |
| QCN0402-25-04P2-10S-02EG-IP64 | 0 | 124 | 20 | 16 Electric / Signal / Ethernet / 220VAC/VDC | 2*Vacuum 2*air | -90KPa~0.7MPa | 0~60 | |
| QCN0801-08S | 0 | 56 | 16 | 8 * Eelctric Signal | 8 * Gas | -100KPa ~ 1.0MPa | 0~60 | |
