BHCN-C-10P-34S

High current slip ring,include 100A, 200A, 250A, 500A, 1500A, 3000A and other specifications, different current specifications are applicable to a variety of different sizes and power plating equipment, with easy installation, light weight and large load flow. Suitable for electrolysis, welding, sewage treatment, material delivery equipment and other industries.

Product Details

BHCN-C-10P-34S	Specification
Current	3800A,1PE,3100A, 360A	6*10A
Voltage	500VAC	220VAC/24VDC
Electrical noise	≤10mΩ(50rpm)	≤30mΩ(50rpm)
Dielectric strength	≥2500V@50Hz	≥1000V@50Hz
Isolation resistance	≥500MΩ@500VDC	≥300MΩ@500VDC
Contact material	Copper graphite	Precious metal, Gold- plated
Operating speed	0-15 rpm
Operating temperature	-20~+60℃
IP protection grade	IP54

Outline drawing
