ECN000-04P-08S

CENO is a technical manufacturing company,it’s has abundant experience in design and assembling for specific industries.CENO can provide you with different customized slip rings.the center hole is available from 0 to 980mm,it’s used for pass through the drive shaft,gas liquid passage,also can integrate with high frequency,fiber,encoder,wave guide,gas and liquid and other joints.ECN000-04P-08S is a solid inner bore slip ring,with 4 rings of 30A power & 8 rings of signal,working speed range 0- 300rpm.It’s widely used for medical equipment,rotation table,industry machine etc,. Any special request please contact with us,our professional R&D team will provide you with the best solution very soon.

Product Details


ECN000-04P-08S

Specification

Circuits & Current

4*30A,8*signal

Voltage

220VAC/VDC

Dielectric strength

≥1000V@50Hz (power)

≥300V@50Hz (signal)

Insulation resistance

≥500MΩ@500VDC (power)

≥100MΩ@300VDC (signal)

Electrical noise

≤70mΩ (50 rpm)

Operating speed

0-300 rpm

Contact material

Precious metal

Housing material

Aluminum alloy

IP grade

IP51

Working temperature

-20℃~+60℃




Outline drawing
