ECN012-04P1-04S-01EM-01EG

Hollow shaft Ethernet slip rings transmit 100M/1000M Ethernet signal. Ethernet connections with a combination of power connections, with advantages of reliable transmitting, no package loss, no cross talk, low loss, low electrical noise and Ethernet cables terminated with RJ45 connectors. Power & signal can be combined to deliver in one body.

Product Details

ECN012-04P1-04S-01EM-01EG	Specification
Current	46A,1422signal,1100M Ethernet, 11000M Ethernet
Voltage	380VAC
Electrical noise	≤70mΩ(50rpm)
Dielectric strength	≥1000V@50Hz
Insulation resistance	500MΩ@500VDC
Operating speed	0-300 rpm
Contact material	precious metals
Operating temperature	-20~+60℃
Through bore size	12.7mm
IP protection grade	IP51

Outline drawing
