ECN038-05P1-02EG Ethernet Slip Ring

ECN038-05P1-02EG is a new designed Ethernet Slip Ring For industrial application from CENO Electronics. This Ethernet Slip Ring is compatible with 5circuits for 5A Electrical and 2group for 1000M Ethernet Signal. And it can be integrated and transfer kinds of data or signal, such as combine the Electric Signal with RF Rotary Joint, FORJ, Pneumatic / Hydraulic Rotary Unions, Profi-Bus, Encoder or Thermocouple etc. For there’s no electromagnetic interference between current and signal, and comply with electromagnetic compatibility requirements, often applied to various industrial machines. For more information about how CENO’s slip ring can fit your specific environment, please contact us.

Product Details

Specification

ECN038-05P1-02EG	Specification
Current & Circuits	5 circuit5A; 2Group1000M Ethernet
Rating Voltage	0~220VAC/VDC
Dielectric strength	≥500VAC@50Hz ≥300VAC@50Hz
Isolation resistance	≥500MΩ@500VDC ≥100MΩ@100VDC
Contact resistance	30mΩ (50rpm)
Contact material	Precious metal / Gold to Gold
Housing material	Aluminum Alloy
Working temperature	-20°C~+60°C
Working humidity	60 %RH
IP protection grade	IP51
Operating speed	0~10rpm
Lead wire size	AW22# Wire Teflon® UL CAT5e
Lead wire length	Rotor : 300mm Stator : 300mm
Inner Diameter	Ø38mm
Rotation way	Fix up stator side with anti-rotation side shaft drives rotor running
