ECN012-10P3-63S-02EG Low temperature slip ring

ECN012-10P3-63S-02EG is CENO new customized low temperature slip ring with multi-channels electric power and circuits Ethernet signal, which is equipped in the machinery stating and working stably in the low temperature environment from -55°C~+70°C. Ethernet signal is an advanced communication technology and widely used in kinds of machinery, it can realize the data transmission of high speed, stably and reliable. For more information please contact us.

Product Details

Specification

ECN012-10P3-63S-02EG	Specification
Current & Circuits	10 circuits * 15A; 63 circuits * Signal; 2 * Ethernet Signal
Rating Voltage	0 ~ 330 VAC/VDC
Dielectric strength	≥1000VAC@50Hz; ≥300VAC@50Hz
Isolation resistance	≥500MΩ@500VDC; ≥100MΩ@300VDC
Contact resistance	≤30mΩ (50rpm)
Contact material	Precious Metal
Housing material	Aluminum Alloy
Working temperature	-40°C~+55°C; -55°C~+70°C
Working humidity	60 %RH
IP protection grade	IP51
Operating speed	0 ~ 300 rpm
Lead wire size	Tin coated Teflon@UL; CAT6
Lead wire length	As customized
Installation	Flange installation
Inner diameter	12.7mm
Working life	5 Million Rotation
