CCN05C

Even though this model CCN05C appearance is very small, compact size, light weight, but operating speed reach 300rpm or higher. We can call it as high speed capsule slip ring, it can not only transmit the signal accurately but also ensure the normal operation of the equipment, with low torque, low loss, long life, it can greatly improve the economic benefits of the enterprise.

Product Details

CCN05C	Specification
Current	1A/circuit
Voltage	240 VAC/DC
Electrical noise	<10m Ω
Dielectric strength	200V@50Hz
Isolation resistance	100MΩ@100VDC
Operating speed	300 rpm
Contact material	Precious Metals
Operating temperature	-20~+80℃
IP protection grade	IP54
OD	5.9mm

Outline drawing
