ECN025-06P3-01EM Ethernet Signal Slip Ring

ECN025-06P3-01EM is CENO Ethernet slip ring with through bore ID25.4mm for industry system. CENO's Ethernet slip ring solutions have been developed to provide reliable products to allow transfer of the Ethernet protocol through a rotating interface. The innovative designs meet the challenge of matching impedance, controlling crosstalk and managing losses. A wide range of solutions are offered within multiple mechanical configurations to meet your special application. More information please contact us.

Product Details

Specification

ECN025-06P3-01EM	Specification
Current & Circuits	6 circuits * 15A; 1 circuits * 100M Ethernet
Rating Voltage	0 ~ 240VAC/VDC
Dielectric strength	≥500VAC@50Hz; ≥300VAC@50Hz
Isolation resistance	≥500MΩ@500VDC; ≥100MΩ@100VDC
Contact resistance	≤30mΩ (50rpm)
Contact material	Precious Metal / Gold to gold
Housing material	Aluminum alloy
Working temperature	-20°C~+60°C
Working humidity	60 %RH
IP protection grade	IP51
Operating speed	0~300rpm
Inner diameter	Ø25.4mm
Outer diameter	Ø86mm
Lead wire size	AWG14# Wire Teflon® UL; CAT5e
Lead wire length	Rotor: 1000mm; Stator: 1000mm
Rotation Way	Flange installation
