ECN000-02P1-04P2-07P-28S-01F

Fiber Optical Electric Slip Ring also called Fiber Optic Rotary Joint (FORJ). The FORJ is widely used in radar system, motion simulator, marine industrial equipment, naval vessel system. We engineer what you need. Our solutions are customized to meet the exact circuits, ratings, and design parameters required for your application.

Product Details

Specification

ECN000-02P1-04P2-07P-28S-01F	Specification
Current	41 circuits electrica / signal / Video signal
Rating voltage	380VAC
Electrical noise	≤70mΩ(50rpm)
Dielectric strength	≥500VAC@50Hz(Power); ≥300VAC@50Hz(Signal)
Insulation resistance	500MΩ@300VDC(Power); 100MΩ@300VDC(Signal)
Working temperature	-40℃~+80℃
Protection grade	IP54
Working speed	0~300rpm
Contact material	Gold to Gold
Fiber type
Fiber channel	1 channel fiber optic

Outline drawing
