ECN000-02P-04S-02F- IP66

This is a customized slip ring with power, signal, fiber optical, it’s also a waterproof slip rings. Designed specifically for underwater operation and waterproof work. According to working environment, the water-proof slip ring could be divided into multiple protection grade, such as IP65, IP66, IP67, IP68 and so on. With stable performance and low torque, working temperature is -20°C~ +80°C. The inner diameter can be customized from 3 mm to 980mm. Any special request please contact with CENO, we will provide the best solution.

Product Details


ECN000-02P-04S-02F- IP66

Specification

Circuits & Current

2*2A,2*20mA,2*Fiber optic

Voltage

500VAC (power)24VDC (signal)

Electrical noise

Max 30mΩ (50rpm)

Dielectric strength

≥1500V@50Hz (power)

≥300V@50Hz (signal)

Insulation resistance

≥500MΩ@500VDC (power)

≥100MΩ@100VDC (signal)

Operating speed

0-50 rpm

Contact material

Precious metal

Housing material

Aluminium alloy ,stainless steel

IP protection grade

IP66

Fiber channels

2 channels (SC connector)

Fiber type

SM & MM

Wave length

1310/1550 nm (SM)

850/1310 nm (SM)




Outline drawing
