SCN series refers to a family of two half style slip ring ,also named separate slip rings. It's a derivation from an independent unit that can transmit current, data signal from stationary to rotating part. The slip ring (rotor) and brush block (stator) are offered as separate components to be mated by the customer in their system. The through bore is 56mm,with one group 485 signal .working speed is 0~200 rpm .Application like electrical test equipment ,manufacturing and process control equipment .
SCN056-03S | Specification |
Rings | 1*485 signal |
Voltage | 0~220VAC |
Dielectric strength | ≥300V@50Hz |
Isolation resistance | ≥100MΩ@100VDC |
Working temperature | -20°C~ +60°C |
Contact material | Precious metal |
Through hole size | 56 mm |
Working speed | 0~200 rpm |
Protection grade | IP00 |
Housing material | Aluminium alloy |
Outline drawing
