ECN025-04P3-05P1-01EG

CENO has been devoted to providing high quality solutions and slip rings for various intelligent automation fields. The ECN025-04P3-05P1-01EG is an economical through hole slip ring with 25.4mm inner bore for Gigabit Ethernet and current mixed transmission. This kind of customized Ethernet slip ring widely used for automatic machine and equipment, we can make 100M Ethernet and 1000M Ethernet slip ring, with stable transmission, no signal crosstalk. The Ethernet slip ring can be combined with electric power, other type of signal, datas, gas, liquid etc.

Product Details


ECN025-04P3-05P1-01EG

Specification

Circuits & Current

4*15A,5*5A,1*1000M Ethernet signal

Voltage

0~380VAC/VDC

Electrical noise

Max 30mΩ (50rpm)

Dielectric strength

≥1000V@50Hz (power)

≥300V@50Hz (signal)

Insulation resistance

≥500MΩ@500VDC (power)

≥100MΩ@100VDC (signal)

Operating speed

0-300 rpm

Contact material

Precious metal

Housing material

Aluminium alloy

IP protection grade

IP51

Through hole size

25.4 mm




Outline drawing
