ECN000-12P2-01PE Water-proof slip ring

This is high protection rotary joint for food machinery, there are 12 circuits transferring power or signal with one circuit for PE. It adopts advanced fiber brush multipoint contact, low friction, long life. When the cover is correctly sealed, it can use for dust prevention and weatherproofed to IP65, housing material is aluminum alloy, mounting flanges can be designed to suit customer's requirements, and ATEX compliant is optional.

Product Details

ECN000-12P2-01PE	Specification
Current	1210A,1PE
Voltage	415VAC
Electrical noise	≤30mΩ (50rpm)
Dielectric strength	≥1500V@50Hz
Isolation resistance	500MΩ@500VDC
Operating speed	0-20 rpm
Contact material	precious metals
Housing material	aluminum alloy
Operating temperature	-20~+60℃
IP protection grade	IP65

Outline drawing
