High temperature thermocouple signal slip ring, It can be used for 360 degree rotating transmission of current and thermocouple signal in high temperature environment. It can work stably in 100-250 degree high temperature environment for a long time. It is mainly used in hot roller, heating device and other high temperature environment.
ECN180-1005-14S | Specification |
Current | 10*5A,14*signal |
Voltage | 380VAC/24VDC |
Electrical noise | ≤70mΩ(50rpm) |
Dielectric strength | ≥1000VAC@50Hz(power) ≥300VAC@50Hz(signal) |
Insulation resistance | ≥500MΩ@100VDC(power) ≥100MΩ@100VDC(signal) |
Operating speed | 0-100 rpm |
Contact material | Precious metals |
Operating temperature | -20~+60℃ |
Through bore size | 180mm |
IP protection grade | IP54 |
Outline drawing
