Some certain application requires that slip ring endure high temperature during operation. Then slip ring takes specific material and use special structure in design. As high temperature slip ring series work under 250℃ condition, we have to take into consideration of the heat dissipation issue in design.
Advantage
Endure high temperature up to 250℃
Anti-corrosion
Aging-resistance & Stable performance
Typical application
Drying oven
Automation machinery
Packaing equipment
Test equipment
| Model | ID (mm) | OD (mm) | CKT No. | Current / Signal | Temperature | Voltage | Working speed | Spec |
|---|---|---|---|---|---|---|---|---|
ACN25-08P2-16S-01EG | 0 | 25 | 25 | 8*10A; 16*2A;1*1000M Ethernet | -40°C~+80°C | 0~240 VAC/VDC | 0~250rpm |  |
ACN25-10P1-32S-01EG | 0 | 25 | 43 | 20*1A; 2*4A; 8*6A; 1*gigabit Ethernet; 12*Cameralink | -40°C~+80°C | 0~48 VAC/VDC | 0~250rpm |  |
| ECN000-25P | 0 | 314 | 25 | 5*60A,20*20A | -20~+120℃ | 600VAC | 0-5 rpm |  |
| ECN000-02P-02P1-01F | 0 | 60 | 5 | 2Circuits*25A; 2Circuits*5A; 1 channel*Fiber | -55~+85℃ | 0~800 VDC | 0-250 rpm | |
ECN000-04P2-02P1-13S-02EM-JZ | 0 | 80 | 21 | 2*15A; 2*10A; 12*TL signal; 2*PE; 2*5A; 2*100M Ethernet | -55~+70℃ | 24 VAC | 0-50 rpm |  |
| ECN038-02P-11S-JZ | 38 | 99 | 15 | 2circuits*18A, 1circuits*PE, 4circuits*RS422, 5circuits*RS232 3circuits*1A | -55℃~+85℃ | 380VAC | 0~100rpm | |
| ECN044-04P2-04S | 44 | 106 | 8 | 4*10A ,4*1A | -40~+85℃ | 0~440VAC/24VDC | 0~600rpm | |
| ECN050-05P3-32P1 | 50 | 119 | 37 | 5*15A, 32*5A | -40°C~+80°C | 250VAC | 0~300rpm |  |
| ECN055-04P1-26S-JZ | 55 | 110 | 30 | 4 circuits*5A, 26 circuits*signal | -55℃~+70℃ | 500VAC@50Hz | 0~50rpm | |
| ECN080-15P-JZ | 80 | 130 | 15 | 5 circuits * 15A, 10 circuits * 5A | -70°C~+85°C | 0~380VAC/DC | 0~60rpm |  |
| ECN088-04P1-37S-JZ | 88 | 140 | 41 | 4*5A,37*signal | -55~+70℃ | 32VAC | / |  |
