The gas-liquid rotary joint is used specially transmiting gas and liquid media, mainly including compressed air, hydrogen, nitrogen, water, oil, coolant and so on.Rotary joints adopt different sealing methods according to different transmission media, mainly including gap sealing, mechanical sealing and sealing of sealing parts. Each type of sealing for rotating joint has its own advantages and limitations.CENO will recomend the relative rotat joint for you base on transferm medium .The connector size in joint is optional, the number of channels could be designed single channel to dozens of channels,and the size, installation could be customized according to working envirenment. It gets stable performance with long lifespan.
Charateristic
Different sealing type
Well performance , long lifespan
Rotating speed up to 800rpm,without maintenance
Customize size and installation
Optional
Cirtuit channel
Presure size, connector specification
Installation
Transfer medium type
Application
Automatic equipment
Chemical pharmacy
Machinery manufacturing
Food processing
Iron and steel metallurgy
Plastic fiber manufacturing
| Model | ID (mm) | OD (mm) | CKT No. | Current/Signal | Air/Gas channel | Pressure | Voltage | Working speed rpm | Spec |
|---|---|---|---|---|---|---|---|---|---|
| QCN01M10 | 4 | 10 | 1 | 1 * water | water | 4Bar | / | 0-5 |  |
| QCN01M3-20 | 20 | 50 | 1 | 1*gas | Gas | 10Bar | 0-5VAC/CDV | 0-50 | |
| QCN01M5-14 | 14 | 55 | 1 | 1* Air | Air | -90KPa ~+20KPa | / | 0 ~ 5000 | |
| QCN02M3-B | 0 | 18 | 2 | 1*air; 1*vacuum | air / vacuum | Air: 0.5MPa Vacuum : -80KPa | / | / | |
| QCN02M3-C | 0 | 18 | 2 | 1*air; 1*vacuum | air / vacuum | Air: 0.5MPa Vacuum : -80KPa | / | / | |
| QCN02M5 | 0 | 26 | 2 | 2*air | Air | 0~0.5 MPa | / | / | |
| QCN0201 | 0 | 56 | 2 | 2*gas | Gas | 10MPa | / | / | |
| QCN02M3-20-05S | 20 | 50 | 2 | 2*gas | Gas | 10Bar | 0-5VAC/CDV | 0-50 |  |
| QCN02M5-00 | 0 | 30 | 2 | 2*air | Air | 0~0.5MPa | / | / | |
| QCN0202 | 0 | 65 | 2 | 2*liquid | liquid | 0.5MPa | / | 100 |  |
| QCN0203 | 0 | 80 | 2 | 1*air G3/8”, 1*Liquid G1/8” | Air/Gas | 1 MPa | / | 100 | |
| QCN03M5-F | 0 | 53 | 3 | 3 * gas | Air/Gas | -100KPa ~ 0.6MPa | / | 0~250 | |
| QCN04M5 | 0 | 34 | 4 | 4*air | Air | -80KPa~0.5MPa | 240VAC | / | |
QCN0401 | 0 | 56 | 4 | 4*gas | Gas | 10MPa | / | / | |
| QCN04M5-12 | 12 | 56 | 4 | 4*gas | Gas | -100KPa ~ 0.6MPa | / | 0~250 | |
| QCN0403 | 0 | 80 | 4 | 2*air G3/8”, 2*Liquid G1/8” | Air/Gas | 1 MPa | / | 100 | |
| QCN0601 | 0 | 56 | 6 | 6 channels * Gas | Air/Gas | -100KPa ~ 0.8MPa | / | 100 | |
| QCN18M5-13 | 0 | 60 | 18 | 18 channels * Air | Air/Gas | 0 ~ 0.5MPa | / | 150 | |
