RCN0806A is CENO new RF Rotary Joint with 8 channels SMA-F for defense systems or combat command system at kinds of levels. It is mainly used in the control and guidance of weapon systems, assisting in air surveillance and reconnaissance, and ensuring accurate navigation and flight safety. Most of CENO RF Rotary joint system products can be customized as customer special application,as the frequency range, channels are optional, and even can be integrate kinds of electric power, signal or data. For more information please contact CENO experts team.
Specification
RCN0806A | Specification | ||
|---|---|---|---|
Channels | 1~2 | 3 | 4~8 |
Interface type | SMA-F(50Ω) | SMA-F(50Ω) | SMA-F(50Ω) |
Frequency range | 0~8GHz | 0~8GHz | 0~6GHz |
Average power | 30W | 30W | 30W |
VSWR, max | 1.5 | 1.6 | 1.6 |
VSWR WOW, max | 0.1 | 0.1 | 0.1 |
Insertion Loss, max | 1.4dB | 1.5dB | 1.5dB |
Insertion loss,wow,max | 0.15dB | 0.15dB | 0.15dB |
Insulation, min | 70dB | 70dB | 70dB |
Outline drawing
