Our rotary joint design adopts the principle of skin effect of high frequency signal and the structure simulation of coaxial cable. To ensure RF rotary joint with the high frequency signal low damage and reliable transmission, it has advantages of long service life, cost-effective, strong anti-interference ability with compact structure.
RCN0205A | Specification |
| Channel number | 1 |
| Frequency range | DC to 26GH |
Connecto | SMA F- SMA F (50ohms) |
| Rotating speed,max | 500rp |
| Peak power,max | 5000W |
| Working temperature | -55℃~+85℃ |
| Insertion loss,WOW | 0.05dB@0-18GHz 0.07dB@18-26GHz |
| IP protection grade | IP40 |
Outline drawing
