Slip ring is designed to use to transmit power, signal or data, pneumatically or hydraulically from a stationary to a rotating platform.It also can be defined to something that goes around an axle like a collar that has 2 ports on it, the inside port rotates independent of the outside one, so that it is possible to attach a motor or sensor on a rotating platform without the wire winding.ECN070-04P3-04S is a through hole slip ring with 70mm inner diameter,4 rings of 15A & 1 ring of Canbus signal.We not only provide products, but also provide solutions.
ECN070-04P3-04S | Specification |
Circuits & Current | 4*15A,1*Canbus (signal) |
Electrical noise | Max 30mΩ |
Dielectric strength | ≥1500V@50Hz (power) ≥300V@50Hz (signal) |
Isolation resistance | ≥500MΩ@500VDC (power) ≥100MΩ@100VDC (signal) |
Operating speed | 0-50 rpm |
Contact material | Precious metal |
Housing material | Aluminium alloy |
IP protection grade | IP51 |
Working temperature | -20°C ~ +60°C |
Through bore size | 70 mm |
Outline drawing
