ECN025-18P2-16S

This is a 25.4mm through hole,34 wires slip ring, the whole body use aluminium alloy material,more durable than engineering plastic material.Transmission power combine with signal,signal type can be optional,we are professional on shielding technology,anti-interference for line to line.We not only provide products,but also provide solutions! According to different requirements of customers for electrical,signal, data,gas and liquid rotary connection,as well as different power parameter requirements,We can provide you with professional design solutions according to the number of wires,current,voltage,signal type,wire length,installation size,rotation speed,working temperature,protection level,etc.

Product Details


ECN025-18P2-16S

Specification

Circuits & Current

18*10A,16*signal

Voltage

0~220VAC

Electrical noise

Max 30mΩ (50rpm)

Dielectric strength

≥1000V@50Hz (power)

≥300V@50Hz (signal)

Isolation resistance

500MΩ@500VDC (power)

100MΩ@300VDC (signal)

Operating speed

0-300 rpm

Contact material

Precious metal

Housing material

Aluminium housing

IP protection grade

IP51

Through hole size

25.4 mm

Working temperature

-20C°~ +60C°




Outline drawing
