This slip ring with standard inner bore size 25.4mm,CENO's through hole slip ring hole size from 3mm to 980mm are optional,the center hole can pass through the drive shaft,gas-liquid passage.it’s can be used in any electromechanical system that requires unrestrained,continuous rotation while transferring power or data from a stationary to a rotating structure.Various signal such as Ethernet,USB,HDMI,SDI, Canbus, Profibus and power are capable to be integrated into one slipring.
ECN025 | Specification |
Circuits number | 6,12,18,24 or more |
Current rating | 5A,10A,15A |
Inner bore size | 25.4mm |
Voltage | 380VAC/VDC |
Electrical noise | 100 milliohms max |
Operating speed | 0-300 rpm or higher |
Contact material | Precious metal |
Housing material | Aluminum alloy |
IP grade | IP54 |
Working temperature | -20℃~+60℃ |
Outline drawing
