ECN050-18P2

We design the through hole slip ring as customer's special requirements.We can provide many parameters for customer to choose ,such as outer diameter,inner diameter ,current,circuit number,IP protection.We supply slip rings in wide range,such as various size,model,wires for various applications with 20 years industry experience and professional engineering team. Our standard through hole slip ring all is with good quality and competitive rate.

Product Details

ECN050-18P2	Specification
Current	18*10A
Rating voltage	380VAC
Electrical noise	≤70mΩ (50rpm)
Dielectric strength	≥1000V@50Hz
Isolation resistance	500MΩ@500VDC
Through bore size	Ø50mm
Working temperature	-20℃~+60℃
Protection grade	IP54
Working speed	0~300rpm
Contact material	Precious metal
Lead wire length	300mm
Housing material	Aluminum alloy

Outline drawing
