ECN127-10P1 is CENO new design Hollow Shaft Slip Ring with ID127mm and 10circuits for 5 Electrical Power for industrial application. Hollow Shaft Slip Ring often called through hole slip ring, through bore slip ring or rotating connector electrical. We are a leading designer and manufacture of electrical slip ring systems for nearly 20 years and have around 5000 designs including many kinds slip ring. The hollow shaft slip ring as a basic slip ring it can be integrated RF, FORJ, Pneumatic/Hydraulic or Signals. For more information about what kinds slip ring suitable your specific applications, please contact us.
Specification
ECN127-10P1 | Specification |
|---|---|
Current & Circuits | 10 circuits*5A |
Rating Voltage | 0~115VAC/VDC |
Dielectric strength | ≥500VAC@50Hz |
Isolation resistance | ≥500MΩ@500VDC |
Contact resistance | 30mΩ (50rpm) |
Contact material | Precious Metal |
Housing material | Stainless steel + Aluminum Alloy |
Working temperature | -20°C~+60°C |
Working humidity | 60 %RH |
IP protection grade | IP51 |
Operating speed | 0~350rpm |
Lead wire size | AW22# Wire Teflon® UL |
Lead wire length | Rotor : 1000mm Stator :1000mm |
Inner Diameter | Ø127mm |
Rotation way | Fix up stator side with anti-rotation side shaft drives rotor running |
Outline drawing
