ACN22-04P-06S-IP67 Water-proof Slip Ring

ACN22-04P-06S-IP67 is CENO new function slip ring capsule with protection grade IP67 and can be up to IP68 for special request. There are kinds of function slip ring at CENO, such as the Anti-explosion slip ring, high / low temperature slip ring, high speed slip ring and waterproof slip ring. The water proof slip ring used in environments such as humidity, corrosion and underwater, which can solve the working problems in the underwater environment. For more information please contact us.

Product Details

Specification

ACN22-04P-06S-IP67	Specification
Current & Circuits	4 circuits * 6A; 6 circuits * 2A
Rating Voltage	0-240VAC/VDC
Dielectric strength	≥500VAC@50Hz
Isolation resistance	≥500MΩ@500VDC
Contact resistance	≤10mΩ (50rpm)
Contact material	Precious Metal
Housing material	Aluminum alloy
Working temperature	-20°C~+80°C
Working humidity	60 %RH
IP protection grade	IP67
Operating speed	0~250rpm
Outer diameter	Ø22mm
Lead wire size	AWG 20# 26# Wire Teflon® UL
Lead wire length	Rotor : 250±5 mm; Stator: 250±5 mm
