ECN160-19P-02EM-IP67 Waterproof Slip Ring

ECN160-19P-02EM-IP67 is CENO Waterproof slip ring for Boats and Ship Machinery. Waterproof slip ring, also known as waterproof conductive slip ring, is a specially designed rotary connector. The principle of waterproof slip ring involves its internal structure and design, which enables it to stably transmit power, signals, data and other information such as optical fiber and radio frequency in harsh environments such as moisture, corrosion and underwater. For more information please contact us.

Product Details

Specification

ECN160-19P-02EM-IP67	Specification
Current & Circuits	2 circuits50A; 4circuits32A; 4circuits * 25A; 9 circuits * 16A; 2 Groups * 100M Ethernet
Rating Voltage	0~400VAC / VDC
Dielectric strength	≥1200VAC@50Hz; ≥300VAC@50Hz
Isolation resistance	≥500MΩ@500VDC; ≥300MΩ@300VDC
Electrical Noise	≤ 30mΩ (50rpm)
IP Grade	IP67
Working humidity	≤ 60%
Working temperature	-20℃ ~ +80℃
Inner diameter	Ø160mm
Operating speed	0~50 rpm
Working Torque	≤ 30N*m
Contact material	Precious Metal / Gold to gold
Housing material	Aluminum Alloy + Stainless steel
Lead wire size	Shielded wire; CAT5e
Lead wire length	Rotor side: 5000mm; Stator side: 5000mm
Rotation Way	Fix up stator side with anti-rotation side shaft drives rotor running
