ECN050-35P-02EM-IP67 Waterproof Slip Ring

ECN050-35P-02EM-IP67 is CENO new Water-proof slip ring with IP67 and ID50mm which is designed for the Port Machinery. Water-proof slip ring adopt advanced materials to get stable performance in high humidity or under water environment, with features of ageing resistance and anti-corrosion. More and more slip rings are used in special high-temperature or low-temperature electromechanical equipment. For more information about CENO slip ring please contact us.

Product Details

Specification

ECN050-35P-02EM-IP67	Specification
Current & Circuits	1 circuit * PE; 7 circuits * 32A;6 circuits * 25A; 5 circuits * 10A; 4 circuits * 16A; 12 circuits * 6A; 2 circuits * 100M Ethernet
Rating Voltage	0 ~ 48VAC / VDC
Dielectric strength	≥1000VAC@50Hz; ≥300VAC@50Hz
Isolation resistance	≥500MΩ@500VDC; ≥100MΩ@300VDC
Electrical Noise	≤30mΩ (50rpm)
IP Grade	IP67
Working humidity	≤ 60%
Working temperature	-20℃ ~ +60℃
Inner diameter	Ø50mm
Outer diameter	Ø180mm
Operating speed	0~100 rpm
Working Torque	≤3N*m
Contact material	Precious Metal / Gold to Gold
Housing material	Aluminum Alloy + Stainless steel
Lead wire size	Lead wires; Shielded wires; CAT5e
Lead wire length	Rotor side: 12000mm; Stator side: 12000mm
Rotation Way	Fix up stator side with anti-rotation side shaft drives rotor running
